12F5C1BBL50A
Description
1. General Information
Part Number: 12F5C1BBL50A（also written as 12.F5.C1B-L50A）
Manufacturer: KEB COMBIVERT
Series: F5 MULTI（modular high‑performance drive）
Type: 3‑phase AC frequency inverter / servo drive
Application: Automation, machine tools, packaging, conveyors, material handling
Motor Types: Asynchronous (induction), synchronous (SMPM/IPM), high‑speed motors
2. Electrical Ratings – Input
Voltage: 3 × 200–230 VAC（230 V nominal）
Frequency: 50 / 60 Hz ±5%
Rated Input Current: 9.5 A
Mains Fuse: 16 A max. (inert)
3. Electrical Ratings – Output
Voltage: 3 × 0–230 VAC
Frequency: 0–800 Hz（standard; up to 1600 Hz high‑speed option）
Rated Power: 2.8 kVA / 1.5 kW
Rated Current: 6.8 A
Switching Frequency: 8 kHz（default）; 16 kHz max.
Overload: 150% for 60 s; 200% for 30 s
4. Control & Interfaces
Control Modes: V/F, Sensorless Vector (SMM), Flux Vector, Servo（position/speed/torque）
Feedback: TTL/HTL encoder, resolver, Sin/Cos, SSI, EnDAT 2.1/2.2, BiSS, Hiperface
Communication: RS‑232/485, Modbus RTU, CANopen, Profibus, Ethernet（optional）
Digital Inputs: 8 × programmable（24 VDC, PNP/NPN）
Digital Outputs: 2 × relay（250 VAC / 5 A）+ 2 × transistor（24 VDC / 0.5 A）
Analog Inputs: 2 × 0–10 V / 4–20 mA（11‑bit）
Analog Outputs: 2 × 0–10 V / 4–20 mA（programmable）
5. Environmental & Mechanical
Operating Temperature: 0 °C to +55 °C
Storage Temperature: -40 °C to +85 °C
Humidity: 5–95% RH（non‑condensing）
Protection Class: IP20（front）, IP00（rear）
Mounting: Panel / DIN rail
Dimensions（W×H×D）: ~120 × 200 × 85 mm
Weight: ~3.2 kg
6. Safety & Compliance
Safety Functions: STO（Safe Torque Off, SIL3）, over/undervoltage, overcurrent, short circuit, overtemperature, ESD protection
Certifications: CE, RoHS, UL, cUL
Standards: EN 61800‑3（EMC）, EN 50178（safety）, IEC 61131‑2
7. Key Features
Integrated braking transistor
Motor temperature monitoring（KTY/PTC/PT1000）
32‑bit positioning
Multi‑language LCD keypad（optional）
Parameter backup/restore
